06070 Kyocera SGS 3.25mm Carbide Drill 2 FLUTE .1280" Diameter .500" Flute 1.50" Length .125" Shank 130° Point
06070 Kyocera SGS 3.25mm Carbide Drill 2 FLUTE .1280" Diameter .500" Flute 1.50" Length .125" Shank 130° Point
Part Number: 06070
SKU: 155507044653
Manufacturer: Kyocera SGS
Regular price
$6.25 USD
Regular price
Sale price
$6.25 USD
Unit price
per
Low stock: 8 left
Couldn't load pickup availability
PRODUCT STATS
| DIAMETER | 0.1280" |
| FLUTE NUMBER | 2 |
| LENGTH OF CUT | 0.5000" |
| OVERALL LENGTH | 1.5" |
| SHANK SIZE | 0.125" |
| SIZE | 3.25mm |
| BRAND | Kyocera SGS |
| CUTTING SIZE | 3.25mm |
| CUT DIRECTION | Up Cut |
| ENDS | Single |
| END STYLE | Drill Point |
| FINISH TYPE | Bright |
| FLUTE DIRECTION | Right Hand |
| FLUTE STYLE | Spiral |
| INCLUDED POINT ANGLE | 130.0° |
| MATERIAL | Solid Carbide |
| MATERIALS CUT | Wood, Plastic, Aluminum, Composite Materials, Steel, Stainless Steel |
| MPN | 06070 |
| WORK DIRECTION | Right Hand |
Kyocera SGS Carbide Drill - PCB Type
Solid Carbide Micro Drill
- 1/8" Shank
130° Included Point Angle
- 4-facet point design stabilizes the drill on entry for superior hole size control
- Mirror surface finishes improve chip flow as hole depth increases
- Application sub-micron grain carbide designed specifically for microtool applications
- ISO certified manufacturing
Applications
- Plastic
- Steel
- Aluminum
- Cast Iron
- Non-ferrous materials
- Titanium
The “rules of the tools” apply. What this means is that all unused tools can be returned for a full refund (minus freight), no questions asked.
